Top Load Tester- Digital SS

Top Load Tester- Digital SS

Top Load Tester- Digital SS


Model No. SS - 1000

PET bottles are susceptible to breakage when the top load is exceeded. When the bottle's top load is greater than the bottle's weight, the excess pressure created by the difference between these weights can cause the bottle to break. Testing the top load of PET bottles is one way to help determine the quality of the material. Thus, we at Presto have designed one of the high-quality lab testing instruments known as the Top Load Tester- Digital model. This testing equipment is highly useful in testing the top load-bearing strength of PET bottles with ease. It measures the compressive load a bottle can bear without getting deformed.

PET bottles are susceptible to breakage when the top load is exceeded. When the bottle's top load is greater than the bottle's weight, the excess pressure created by the difference between these weights can cause the bottle to break. Testing the top load of PET bottles is one way to help determin..read more


PDF icon Video icon

Product Description

The digital model of the Presto top load tester has been made with a digital display that will provide you with accurate and repeatable test results. It comes with inverted straight plates with zero gripping support that will help the manufacturers to conduct the top load test on the bottles with ease. With its bright LED display and feather touch controls, the users can easily operate this lab testing instrument and test their bottles against top load. Besides this, it has been embedded with highly advanced features that include over load protection, over travel protection, speed control option, feather touch controls and a bright LED display to conduct the test accurately. By testing the top load strength of the materials, the manufacturers can easily measure the compressive strength of such containers to ensure they do not deform or break when subjected to axial forces during the processes of filling, closure, storage, and transport.

Product Specification

  • Model availablein various LoadRange - 100Kgf

  • Accuracy - ±2%fullscale (with master load)

  • Least Count/Resolution - 0.1 Kgf

  • Test Speed - * 24 ±5 mm / min.

  • Power - 220V, Single phase, 50 Hz

  • Display - LEDdisplay(7 Segment)

  • LoadMonitoring - Peak Load indicatorwith Digitalreadout and peak hold feature (result save in memory)

  • CompressionPlate - Diaof CompressionPlate - 180mm ±5mm

  • Maximum Height of the Bottle that can be tested- 500 mm

Product Features

  • Inverted straight plates for zero slip gripping support
  • Digital Display for accuracy and repeatability
  • In-house calibration facility
  • Peak Load Hold Facility (save in memory)
  • Data output in digital display form
  • Highly accurate test results under compressive force
  • Bright LED display
  • Feather touch controls
  • Overload protection
  • Over travel Protection
  • Speed control option
  • The Stainless Steel body makes the instrument durable & rust free
